Secure digital input/output interface (SDIO)
RM0008
The bus transaction for a GEN_CMD is the same as the single-block read or write
commands (WRITE_BLOCK, CMD24 or READ_SINGLE_BLOCK,CMD17). In this case, the
argument denotes the direction of the data transfer rather than the address, and the data
block has vendor-specific format and meaning.
The card must be selected (in transfer state) before sending GEN_CMD (CMD56). The data
block size is defined by SET_BLOCKLEN (CMD16). The response to GEN_CMD (CMD56)
is in R1b format.
Command types
Both application-specific and general commands are divided into the four following types:
●
●
●
●
broadcast command (BC) : sent to all cards; no responses returned.
broadcast command with response (BCR): sent to all cards; responses received
from all cards simultaneously.
addressed (point-to-point) command (AC): sent to the card that is selected; does
not include a data transfer on the SDIO_D line(s).
addressed (point-to-point) data transfer command (ADTC): sent to the card that is
selected; includes a data transfer on the SDIO_D line(s).
Command formats
See Table 121 on page 464 for command formats.
Commands for the MultiMediaCard/SD module
Table 137. Block-oriented write commands
CMD
index
Type
Argument
Response
format
Abbreviation
Description
CMD23 ac
CMD24 adtc
[31:16] set to 0
[15:0] number
of blocks
[31:0] data
address
R1
R1
SET_BLOCK_COUNT
WRITE_BLOCK
Defines the number of blocks which
are going to be transferred in the
multiple-block read or write command
that follows.
Writes a block of the size selected by
the SET_BLOCKLEN command.
Continuously writes blocks of data
CMD25 adtc
[31:0] data
address
R1
WRITE_MULTIPLE_BLOCK
until a STOP_TRANSMISSION
follows or the requested number of
blocks has been received.
Programming of the card identification
register. This command must be
issued only once per card. The card
CMD26 adtc
[31:0] stuff bits R1
PROGRAM_CID
contains hardware to prevent this
operation after the first programming.
Normally this command is reserved
for manufacturer.
CMD27 adtc
488/995
[31:0] stuff bits R1
PROGRAM_CSD
Doc ID 13902 Rev 9
Programming of the programmable
bits of the CSD.
